Twin Alternating, 60Lpm, 78,000L capacity*

Puretec SOL60-TA Commercial/Industrial Water Softener

The SOL60-TA “twin alternating” water softener provides uninterrupted softened water even during regeneration. The SOL-TA series is recommended for industrial/ commercial use or where continuous softened water is critical for the protection of valuable equipment. The SOL-TA series provides more than just twice the capacity of the SOL60 or SOL45. Because it can regenerate many times per day while still producing soft water, it is ideal in situations with high or variable water demand.

Find a Puretec Dealer

Features & Benefits

• Large capacity separate resin and brine tank.
• Fully automatic operation. Just add salt.
• Weather resistant cover for controller.
• Optional bypass valve available (WTV5000).
• 1” connections means minimum pressure loss.
• Stores system configuration and operation data in non-volatile memory.
• Can also remove traces of metals such as copper, lead and manganese.

Specifications

Ordering Code

SOL60-TA

Valve

Twin Alternating

Flow Rate

60 Lpm

Maximum Flow Rate

100 Lpm

Capacity

78,000 litres per regeneration

Connection

1” Male BSPT, ¾” Drain

Min/Max Pressure

138 - 862 kPa

Operating Temperature

5 - 40°C (41 - 104°F)

Power Supply

230V AC / 50 Hz

Warranty

1 year^

Replacement Media Kits

RMK-SOL60 (2x required)

Accessories

WTV5090 - Micro switch for automation of external equipment.
WTV5000 - Bypass assembly for testing, and maintenance.
PTE30 - Hardness test kit
WTV5050 - Blending valve for partial hardness removal
SS5000 - SoftenerSafe Media, 5 litres

Note: Capacities are based on a hardness of 100ppm. 1. Recommended maximum of 4 regenerations per day. 2. The flow rate while the filter backwashes, needs to be equal to the stated service flow to maintain proper backwash functionality, which is critical for optimum performance of filtration systems.

Chlorine (free Chlorine) tolerance is 1ppm - high chlorine levels permanently damage the softening resin & is not covered under warranty. If chlorine exceeds this limit, we recommend a carbon pre-filter such as the WH2 or CFS Series. Please refer to Puretec for a specific recommendation. In any case, a carbon pre-filter is recommended to protect against chlorine spikes & prolong the resin life.

^1 year replacement parts and labour.
